Marin TAM XR 2026

£4,299.00

Marin Tam XR 2026 Mountain BikeThe Marin Tam XR is the range topping short travel trail bike built for riders who want maximum speed, efficiency and control. The Series 4 aluminium frame uses 120 mm of IsoTrac flexstay suspension for smooth support on rough terrain. A Fox 34 SL Performance — Read More

GTIN (UPC): 26MARINTAMXR Categories: , Brand:

Spread the cost from £119.42 monthly*

Buying Guides

Description

Marin Tam XR 2026 Mountain Bike

The Marin Tam XR is the range topping short travel trail bike built for riders who want maximum speed, efficiency and control. The Series 4 aluminium frame uses 120 mm of IsoTrac flexstay suspension for smooth support on rough terrain. A Fox 34 SL Performance Elite fork, Float SL shock, Shimano Deore Di2 wireless drivetrain and a PNW Loam dropper post create a lightweight and responsive setup for XC loops, long days and technical singletrack. With space for two bottles, internal cable routing and easy service parts, the Tam XR is designed for riders who want top level performance without complication.

Key Features

  • Series 4 aluminium frame

  • 120 mm IsoTrac flexstay suspension

  • Fox 34 SL Performance Elite 130 mm fork

  • Fox Float SL Performance Elite rear shock

  • Shimano Deore Di2 12 speed drivetrain

  • SRAM Motiv Silver four piston brakes

  • WTB KOM Light i30 rims with WTB X7 hubs

  • Maxxis Rekon Race 29 inch tyres

  • PNW Loam dropper post

  • Internal cable routing

  • Room for two bottles

Lightweight And Efficient Frame

The Series 4 aluminium frame uses the IsoTrac flexstay suspension layout for 120 mm of smooth, efficient travel. It reduces weight and complexity while keeping the bike responsive on climbs and controlled on descents. The geometry uses a 65 degree head angle and 76 degree seat tube angle for stability and climbing comfort.

Fox Performance Elite Suspension

A Fox 34 SL Performance Elite fork with the GRIP X damper provides lightweight support and precise control. The matching Float SL Performance Elite shock is tuned specifically for the Tam XR, offering consistent damping and traction on technical terrain.

Wireless Drivetrain And Powerful Brakes

Shimano Deore Di2 delivers fast, accurate wireless shifting with a wide range 10 51T cassette for steep climbs. SRAM Motiv Silver four piston brakes with 180 mm rotors provide strong and reliable stopping power.

Lightweight Wheels And Fast Rolling Tyres

WTB KOM Light i30 rims, WTB X7 hubs and Maxxis Rekon Race tyres create a fast rolling and lightweight wheel setup. The tyres are tubeless ready for improved grip and puncture protection.

Bike specifications are advised by the manufacturer and can be subject to change without prior warning.

Please call our helpful sales team on 01539 821 443 or email us for the latest up-to-date product information.

Specification

Frame

All new Series 4 Aluminum, 29" Wheels, 120mm IsoTrac Suspension Platform, Full Internal Cable Routing, Chainstay Mounted 160MM DM, 148x12mm Boost Thru-Axle, 73mm BB Shell, ISCG 05 Tabs
Rear Shock

Fox Float SL Performance, 3-Pos Compresion Adjust, EVOL LV Air Spring, 190x45mm, 30x8m Hardware, 0.6 VC, CL+ RF CMF Tune
Fork

Fox 34SL Performance Elite, 130mm Travel, Grip X Damper, Kabolt SL Axle 110x15mm, Tapered Steerer Tube, 44mm Offset
Head Set

FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2"
Stem

Marin 3D Forged Alloy, 55mm
Handle Bars

Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 30mm Rise, 5 Up, 9 Back
Tape Grips

Marin Grizzly Lock-On
Brakes

SRAM Motiv Silver
Brake Levers

SRAM Motiv Silver
Rear Derailleur

Shimano Deore Di2, 12-Speed, SGS
Rear Hub

WTB X7, 148×12, Staright Pull, 28H, 6-Bolt Disc , MicroSpline FH
Front Hub

WTB X7, 110×15, Staright Pull, 28H, 6-Bolt Disc
Shift Levers

Shimano Deore Di2, 12-Speed
Cassette

Shimano, Deore 12-Speed, 10-51T
Chainset

Race Face AFfect, 32T Steel Ring, 24mm Spindle, 170mm, 55.5mm CL
Wheels

WTB KOM Light i30, 28H
Front Tyre

Maxxis Rekon Race, 29×2.35", Folding Bead, Tubeless Ready
Rear Tyre

Maxxis Rekon Race, 29×2.35", Folding Bead, Tubeless Ready
Saddle

Marin Speed Concept
Seat Post

PNW Loam Dropper Post Gen 2+, Range Lever MMX Clamp, Adjustable Travel, 30.9mm Diameter, S = 150MM / M = 170MM / L-XL = 200MM
Discipline

MTB
Material

Aluminium
Wheel size

29"
Electric

No
Season

2026
