The Amflow TL Carbon is a lightweight full‑carbon touring and commuting e‑bike with FOX suspension, the Avinox M2 motor, an 800 Wh battery and a 200 kg load rating for long‑distance travel and daily use. Fully Loaded for Adventure.
Showing the single result
The Amflow TL Carbon is Amflow’s first touring and commuting e‑bike. It uses a 2.9kg full‑carbon frame and arrives fully equipped for daily use. The complete bike weighs around 22.6kg, which is light for a full‑suspension machine with racks, lights and mudguards fitted. Amflow describe it as an SUV e‑bike, designed to move smoothly through the city, carry a heavy load on tour and stay composed on rougher ground.
The TL Carbon frame keeps weight low while staying strong enough for a 200 kg total system rating. The geometry is comfort‑focused for long days and stable handling. The bike is built to carry a rider up to 125 kg, plus up to 20 kg on the front rack and 27 kg on the rear rack.
The TL uses a FOX AWL Sport fork with 120 mm travel and a FOX FLOAT Rhythm shock with 105 mm travel. Both are tuned specifically for the TL platform. This setup smooths broken tarmac, keeps the bike settled when loaded and stays comfortable over roots and rougher tracks.
Power comes from the DJI Avinox M2 drive unit. It is rated at 250 W with up to 125 Nm peak torque. The removable 800 Wh battery offers up to 172 km of range. Riders can add an optional 480 Wh secondary battery to reach 1280 Wh total capacity. An optional charging hub can charge up to four batteries in sequence.
The TL Carbon uses the Avinox DPC100 2‑inch OLED display with two wireless bar controllers. It includes SmoothShift electronic shifting, a TRP E.A.S.I. derailleur, traction control, offline navigation, Apple Find My tracking, Bluetooth heart‑rate control and GPS with OTA updates.
The bike arrives fully equipped with mudguards, a MIK HD rear rack, front and rear lights, a kickstand and pedals. Modular mounting points make it easy to add panniers, bags or a trailer using the optional trailer thru‑axle. The wheels can be switched between 27.5 inch and 29 inch to suit the terrain.
The TL Carbon is built for riders who want a light, capable and fully equipped e‑bike for commuting, touring and mixed terrain riding.
Commuting, touring and mixed terrain riding including towpaths, rough tracks and broken tarmac.
It is rated to around 200 kg total weight, including the bike, rider and luggage.
The TL Carbon uses the DJI Avinox M2 motor with up to 125 Nm peak torque.
Up to 172 km from the 800 Wh battery, expandable to 1280 Wh with the optional 480 Wh secondary battery.
Yes. It includes mudguards, a MIK HD rear rack, lights, kickstand and pedals as standard.
Yes. It can switch between 27.5 inch and 29 inch wheels.
